Motorola MVME5110
High-Performance VMEbus Processor Module
Product Overview
The Motorola MVME5110 is a high-performance VMEbus processor module designed for demanding real-time applications. Based on the PowerPC 604e processor, it delivers exceptional processing power while maintaining compatibility with the VMEbus standard, making it ideal for industrial control, aerospace, defense, and telecommunications systems.
Key Features
- PowerPC 604e processor up to 200 MHz
- 64-bit VMEbus interface (P1 and P2 connectors)
- Up to 128 MB of ECC-protected SDRAM
- 16 MB Flash memory for firmware storage
- Dual Ethernet ports (10/100 Mbps)
- Two serial ports (RS-232/422/485)
Technical Benefits
- High-performance RISC architecture
- Advanced cache management
- Real-time processing capabilities
- Robust industrial-grade design
- VMEbus compatibility for legacy systems
- Long-term availability and support
Technical Specifications
Processor & Memory
| Processor: | PowerPC 604e, up to 200 MHz |
| System Memory: | 16-128 MB ECC-protected SDRAM |
| Flash Memory: | 16 MB (boot code and OS storage) |
| Cache: | 32 KB instruction, 32 KB data |
| MMU: | Full 64-entry TLB |
VMEbus Interface
| Bus Type: | VME64 (IEEE-1014-1987) |
| Data Width: | 32/64-bit |
| Address Width: | 32/64-bit |
| Transfer Rate: | Up to 40 MB/s (burst mode) |
| Interrupts: | 7 levels, vectorized |
I/O Interfaces
| Ethernet: | 2 x 10/100 Mbps (RJ-45) |
| Serial Ports: | 2 x RS-232/422/485 |
| Parallel Port: | IEEE 1284-compliant |
| USB: | 1 x USB 1.1 |
| Watchdog Timer: | Programmable, up to 60 seconds |
Physical & Environmental
| Form Factor: | 6U VMEbus card (160mm x 233.35mm) |
| Power Requirements: | +5V @ 3.0A, +12V @ 0.5A |
| Temperature: | -20°C to +60°C (industrial) |
| Humidity: | 5-95% non-condensing |
| Weight: | Approximately 500g |
Software Support
The MVME5110 supports a wide range of real-time operating systems and development environments, ensuring compatibility with existing and new applications:
VxWorks
RTLinux
QNX
Solaris
Linux
Applications
System Integration
The MVME5110 is designed for seamless integration into VMEbus-based systems, providing a reliable platform for mission-critical applications. It can be combined with various VMEbus modules for comprehensive system solutions:
Memory Modules
I/O Modules
Storage Modules
Communication Modules
Power Supplies
