ABB P8403 Control Module
- Product Code: P8403
- Availability: In Stock
ABB P8403
Technical Documentation
P8403 Process Control Module
Product Code: P8403
Advant OCS System
Revision: 2.1
General Description
The ABB P8403 is a high-performance process control module designed for use in the Advant Open Control System (OCS). It provides reliable and precise control functions for industrial automation processes, offering advanced capabilities for process monitoring and control.
Key Features
- 16 digital inputs / 16 digital outputs
- 8 analog inputs (4-20 mA)
- 4 analog outputs (4-20 mA)
- Programmable function blocks
- Redundant configuration options
- High-speed processing (100 ms scan time)
Technical Specifications
| Power Supply: | 24 VDC ±10% |
| Power Consumption: | Max 5 W |
| Operating Temperature: | -20°C to +60°C |
| Storage Temperature: | -40°C to +85°C |
| Humidity: | 5% to 95% non-condensing |
| Dimensions (HxWxD): | 120 x 160 x 80 mm |
I/O Configuration
| Channel Type | Quantity | Range/Specification | Resolution/Accuracy |
|---|---|---|---|
| Analog Input | 8 | 4-20 mA, 0-10 V | 16-bit, ±0.1% |
| Analog Output | 4 | 4-20 mA, 0-10 V | 16-bit, ±0.2% |
| Digital Input | 16 | 24 VDC | Sink/Source configurable |
| Digital Output | 16 | 24 VDC, 0.5 A per channel | Sink/Source configurable |
Approval Certifications
- CE
- UL 508
- CSA C22.2 No. 14
- Atex/IECEx (Zone 2)
- GL (Marine)
- SIL 2 Certified
Communication
- Profibus DP
- Modbus TCP/RTU
- EtherNet/IP
- ABB AC 800M bus
Typical Applications
- Chemical and petrochemical processes
- Power generation and distribution
- Pulp and paper manufacturing
- Water and wastewater treatment
- Food and beverage production
- Pharmaceutical manufacturing
ABB © 2025
All rights reserved
Document: P8403-DOC-EN
Date: July 2025
