GE IC9445C208
PACSystems™ RX3i Communication Interface Module | Technical Specification Sheet
Product Overview
The GE IC9445C208 is a high-speed communication interface module designed for GE's PACSystems™ RX3i programmable automation controller (PAC) platform. Engineered for industrial automation applications, this module enables seamless connectivity between the RX3i controller and industrial networks, supporting real-time data exchange, remote monitoring, and device integration across manufacturing, power generation, and process control systems.
Key features include dual Ethernet ports for redundant network configurations, support for multiple industrial protocols (Profinet, Ethernet/IP, Modbus TCP), and ruggedized construction for harsh industrial environments. The module is fully compatible with GE's CIMPLICITY® HMI/SCADA software and third-party control systems, ensuring interoperability and scalability.
Technical Specifications
Electrical Parameters
Operating Voltage: 5 VDC (from RX3i backplane)
Power Consumption: ≤1.2 W
Input/Output Signals: Digital (RJ45 Ethernet)
Isolation: 2500 VDC (signal to backplane)
Communication Features
Network Interfaces: 2× RJ45 (10/100/1000 Mbps)
Supported Protocols: Profinet IO, Ethernet/IP, Modbus TCP
Data Transfer Rate: Up to 1 Gbps
Redundancy: Media Redundancy Protocol (MRP) support
Environmental Ratings
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Storage Temperature: -40°C to +85°C (-40°F to 185°F)
Humidity: 5% to 95% (non-condensing)
Shock Resistance: 30 g (11 ms, half-sine)
Mechanical Details
Dimensions (W×H×D): 45×120×150 mm
Mounting: RX3i PLC Chassis (7-slot/10-slot)
Material: Metal Alloy (chassis) + Polycarbonate
Weight: 0.35 kg (0.77 lbs)
Certifications & Compliance
CE (EN 61131-2, EN 61000-6-2)
UL/cUL Listed (UL 508, CSA C22.2 No. 142)
ATEX: Ex II 3G Ex nA IIC T4 Gc
RoHS 2 Compliant (2011/65/EU)
System Compatibility
Controllers: GE PACSystems™ RX3i (IC695CHS012/020)
Software: Proficy Machine Edition v9.0+
HMI/SCADA: CIMPLICITY® v10+ , iFIX v6.0+
Third-Party: Siemens SIMATIC, Rockwell Logix
Installation & Configuration
Installation Guidelines
1. Power off the RX3i PLC chassis before module installation.
2. Insert the IC9445C208 into an available RX3i backplane slot (slot 0–6 for 7-slot chassis).
3. Secure the module with the locking lever (torque: 0.5 Nm) to ensure proper backplane contact.
4. Connect Ethernet cables to the RJ45 ports (Port 1 for primary network, Port 2 for redundancy).
5. Power on the chassis and verify the module status LED (green = operational, red = fault).
Configuration Steps
1. Launch Proficy Machine Edition and connect to the RX3i controller via USB/serial.
2. Navigate to the "Communication Modules" menu and select the IC9445C208.
3. Configure network parameters (IP address, subnet mask, gateway) and enable desired protocols.
4. Set up redundancy parameters (if applicable) and download the configuration to the module.
5. Test communication with network devices using the built-in diagnostic tools in Proficy ME.
Diagnostic & Troubleshooting
LED Status Indicators
• PWR (Green): Module powered on
• FAULT (Red): Hardware/software error
• LINK/ACT (Blue): Network link/activity
• RDY (Amber): Module ready for configuration
Common Issues & Solutions
• No Power (PWR LED Off): Check backplane power supply; verify module seating in slot.
• Network Link Failure: Test Ethernet cable; confirm switch port configuration.
• Protocol Communication Error: Validate protocol settings; check firewall rules.
• Fault LED Illuminated: Reset module; check Proficy ME for diagnostic error codes.
Warranty & Technical Support
• Standard Warranty: 36 months from the date of shipment (covers manufacturing defects and workmanship).
• Extended Warranty: Up to 5 years available via GE Digital Service Agreements.
• Technical Support: 24/7 global support via GE Digital Customer Center (Phone: +1-800-433-2682 | Email: pacsystems.support@ge.com).
• Documentation: Access datasheets, manuals, and firmware updates at gedigital.com/pacsystems-rx3i.
• Repair Services: GE Authorized Service Centers offer repair and recalibration for industrial modules worldwide.
