GE DS200GGDAG1A Gate Driver Board
- Product Code: DS200GGDAG1A
- Availability: In Stock
GE DS200GGDAG1A
Gate Driver Board
Product Overview
The GE DS200GGDAG1A is a critical gate driver board designed for use in GE's Mark V and Mark VIe turbine control systems. This specialized board provides precise control signals to power semiconductor devices (IGBTs or thyristors) in power conversion modules, ensuring reliable operation of variable frequency drives and power supplies in industrial turbine applications. Its robust design delivers consistent performance in demanding environments.
Key Features
- • Precision gate drive signals for power semiconductor devices
- • Integrated protection circuits (overvoltage, overcurrent, short circuit)
- • Optical isolation between control and power circuits
- • Status monitoring and diagnostic feedback to main controller
- • Compatible with GE Mark V/VIe turbine control systems
- • Rugged construction for industrial environments
Technical Specifications
| Parameter | Details |
|---|---|
| Input Voltage | +5V DC and ±15V DC from system power supply |
| Output Signals | Isolated gate drive signals (up to ±20V) |
| Isolation Rating | 2500V RMS between control and power sections |
| Operating Temperature | 0°C to +60°C (+32°F to +140°F) |
| Dimensions | 180mm x 120mm (7.09" x 4.72") |
| Mounting | DIN rail or panel mount via mounting holes |
Typical Applications
- Gas and steam turbine control systems
- Generator excitation systems
- Industrial power conversion modules
- Variable frequency drives in power plants
- GE Mark V/VIe turbine control system upgrades
- High-power motor drive systems
