Allen-Bradley 81001-451-82-R Industrial Connector

  • 0 reviews
  • Write a review
    • Product Code: 81001-451-82-R
    • Availability: In Stock

    Allen-Bradley 81001-451-82-R

    Intermediate Technical Documentation

    Product Overview

    The Allen-Bradley 81001-451-82-R is a high-reliability industrial connector assembly designed for use in automated control systems. This component facilitates secure electrical connections in demanding industrial environments, ensuring consistent performance under varying operational conditions.

    Primary applications include integration with programmable logic controllers (PLCs), motor control centers, and industrial machinery where robust connectivity is critical for system integrity.

    Technical Parameters

    Electrical Ratings

    • Maximum Voltage: 600V AC/DC
    • Current Rating: 10A continuous
    • Insulation Resistance: ≥100MΩ at 500V DC

    Environmental Limits

    • Operating Temp: -40°C to +85°C
    • Storage Temp: -55°C to +105°C
    • Humidity: 5% to 95% RH, non-condensing

    Mechanical Characteristics

    Feature Specification
    Connector Type 7-pin circular, M12 x 1
    Housing Material Nickel-plated brass
    Cable Length 2 meters (6.56 ft)
    Protection Rating IP67 when mated

    Installation Notes

    1. Ensure mating connector is clean and free from debris before installation
    2. Hand-tighten only; do not use tools to avoid damage to threads
    3. Verify proper alignment before coupling to prevent pin damage
    4. Cable bending radius should not exceed 5x cable diameter during installation
    5. Use appropriate torque (0.5-0.7 Nm) when securing mounting hardware

    Document Revision: 1.2 | Last Updated: 2023-09

    © Rockwell Automation, Inc.
