ABB 1TGE120021R0810 Industrial Drive Control Module

  • 0 reviews
  • Write a review
    • Product Code: 1TGE120021R0810
    • Availability: In Stock


    ABB 1TGE120021R0810 Product Document
    ABB 1TGE120021R0810
    Industrial Drive Control Module | Technical Specification Sheet
    Product Overview
    The ABB 1TGE120021R0810 is a high-performance control module designed for integration with ABB industrial drive systems. Engineered for reliability and precision, this module serves as a critical component in motor control applications across manufacturing, energy, and process industries, supporting seamless communication and real-time drive parameter management.
    Key design features include robust industrial-grade construction, compatibility with ABB ACS880 and ACS580 drive series, and compliance with international safety and electromagnetic compatibility (EMC) standards.
    Technical Specifications
    Electrical Parameters
    Supply Voltage: 24 VDC ±10%
    Power Consumption: ≤5 W
    Input Signal Type: Analog (4-20 mA) / Digital (24 VDC)
    Output Signal Type: Relay (5 A/250 VAC) / Analog (0-10 V)
    Environmental Ratings
    Operating Temperature: -20°C to +60°C
    Storage Temperature: -40°C to +85°C
    Humidity: 5% to 95% (non-condensing)
    Protection Class: IP20 (front) / IP00 (rear)
    Mechanical Details
    Dimensions (W×H×D): 120×150×80 mm
    Mounting Type: DIN Rail (35 mm) / Panel Mount
    Material: Polycarbonate (PC) + Metal Alloy
    Weight: 0.8 kg
    Certifications
    CE (EN 61010-1, EN 61800-3)
    UL/cUL Listed (UL 508)
    RoHS Compliant (2011/65/EU)
    ATEX (for hazardous areas: Ex II 2G Ex ib IIC T4)
    Compatibility & Installation
    Compatible ABB Drives
    • ACS880 Series: ACS880-01, ACS880-04, ACS880-11
    • ACS580 Series: ACS580-01, ACS580-04
    • ACS380 Series (with adapter module)
    • ACS180 Series (for light industrial applications)
    Installation Guidelines
    1. Mount the module on a 35 mm DIN rail or panel (torque: 0.8 Nm).
    2. Connect power supply (24 VDC) to terminals 1 (+) and 2 (-).
    3. Establish communication via Modbus RTU/Profibus DP (terminal block X2).
    4. Perform factory reset (DIP switch S1) before initial configuration.
    Warranty & Technical Support
    • Standard Warranty: 24 months from the date of delivery (covers manufacturing defects).
    • Extended Warranty: Up to 5 years available via ABB Service Agreements.
    • Technical Support: Global ABB service network (24/7 hotline: +46 31 748 1000 | email: drive.support@abb.com).
    • Documentation: Access full manuals at https://new.abb.com/drives.
