Honeywell CC-TAIM01 Analog Input Modul

  • 0 reviews
  • Write a review
    • Product Code: CC-TAIM01
    • Availability: In Stock

    Honeywell CC-TAIM01 Intermediate Document

    Notice

    This intermediate document provides technical specifications and configuration guidelines for the Honeywell CC-TAIM01 module.

    1. Module Overview

    The Honeywell CC-TAIM01 is a high-performance analog input module designed for use with the Experion® Process Knowledge System (PKS). It features:

    • 16-channel analog input with configurable I/O types
    • High-resolution 24-bit analog-to-digital conversion
    • Isolated inputs for enhanced noise immunity
    • Configurable sampling rates and filtering options
    • Built-in signal conditioning and linearization capabilities
    • Diagnostic capabilities for continuous health monitoring

    2. Technical Specifications

    Parameter Specification
    Input Channels 16 differential or 32 single-ended inputs
    Input Types
    • 4-20 mA (loop-powered or voltage-driven)
    • 0-10 VDC
    • Thermocouples (J, K, T, E, R, S, B, N)
    • RTDs (PT100, PT500, PT1000)
    Resolution 24-bit with effective resolution of 16 bits
    Accuracy ±0.025% of full scale
    Sampling Rate 0.1 to 100 samples per second (configurable)
    Isolation 1500 V rms channel-to-channel and channel-to-system
    Filtering Digital filtering with configurable cutoff frequency
    Power Consumption ≤15 W
    Operating Temperature -40°C to +85°C

    3. Configuration Guidelines

    To configure the Honeywell CC-TAIM01 module:

    1. Install the module in a compatible Experion® I/O chassis.
    2. Connect the appropriate field wiring to the input terminals.
    3. Access the configuration utility through the Experion® system.
    4. Configure the module parameters:
      • Define input type for each channel
      • Set scaling parameters and engineering units
      • Configure sampling rate and filtering options
      • Set alarm limits and deadbands
      • Enable diagnostic features and fault responses
    5. Perform loop calibration for precise measurements.
    6. Verify communication with the control system.
    7. Implement appropriate safety interlocks and redundancy.

    4. Safety Considerations

    The module provides several safety features to ensure reliable operation:

    • Redundant communication paths for fault tolerance
    • Continuous self-diagnostics with fault reporting
    • Overvoltage and surge protection on all inputs
    • Compliance with relevant safety standards (IEC 61508, SIL 2)
    • Configurable fail-safe behavior for critical applications
    • Secure firmware updates and configuration management

    Honeywell CC-TAIM01 Intermediate Document | Last updated: July 1, 2025
