ELAU ISH100/30044/0/1/00/0/00/01/00 Servo Motor

  • 0 reviews
  • Write a review
    • Product Code: ISH100/30044/0/1/00/0/00/01/00
    • Availability: In Stock

    ELAU ISH100/30044/0/1/00/0/00/01/00 Servo Motor

    The ELAU ISH100/30044/0/1/00/0/00/01/00 represents a high-performance servo motor designed for precision motion control applications. Engineered to deliver exceptional torque density and dynamic response, this servo motor is ideal for demanding automation tasks across various industries.

    Key Features

    • High Torque Density: Delivers up to 100 Nm of continuous torque with compact dimensions.
    • High-Speed Capability: Operates at speeds up to 3000 RPM with excellent stability.
    • Precision Control: Equipped with high-resolution feedback systems for accurate positioning.
    • Robust Design: IP65-rated enclosure ensures reliable operation in harsh industrial environments.
    • Energy Efficient: Optimized design reduces power consumption while maintaining high performance.
    • Integrated Safety Features: Includes STO (Safe Torque Off) functionality for enhanced machine safety.

    Technical Specifications

    Parameter Value
    Continuous Torque 100 Nm
    Peak Torque 300 Nm
    Rated Speed 3000 RPM
    Max Speed 4000 RPM
    Power Rating 30 kW
    Supply Voltage 400 VAC
    Feedback System Sin/Cos Encoder, 20-bit resolution
    Protection Class IP65
    Weight 44 kg

    Performance Characteristics

    • Excellent dynamic response with short acceleration and deceleration times
    • Low torque ripple for smooth operation at all speeds
    • High overload capacity for demanding applications
    • Optimized thermal management for continuous operation

    Application Scenarios

    This servo motor is well-suited for a variety of industrial applications, including:

    • High-precision CNC machining centers
    • Robotic arms and automation systems
    • Packaging and labeling machinery
    • Printing presses and converting equipment
    • Textile machinery requiring precise tension control

    Compatibility

    The ISH100/30044/0/1/00/0/00/01/00 is fully compatible with:

    • ELAU's PacDrive 3 automation system
    • Major industry-standard servo drives with compatible feedback interfaces
    • PLC systems supporting EtherCAT, Profibus, or other fieldbus protocols
    • ELAU's motion control software suite for easy integration and configuration

    Note: Please refer to the official ELAU documentation for detailed installation guidelines, wiring diagrams, and maintenance procedures specific to your application.
