Bently Nevada 3701/55 323174-01 Proximity Probe
- Product Code: 3701/55 323174-01 Proximity Probe
- Availability: In Stock
Bently Nevada 3701/55 323174-01
5mm Proximity Probe System
Product Overview
The Bently Nevada 3701/55 323174-01 is a high-performance 5mm proximity probe system designed for continuous monitoring of shaft vibration, position, and eccentricity in rotating machinery. Engineered to meet the demanding requirements of critical industrial applications, this system delivers accurate and reliable measurements in harsh environments.
Key Features
- High-resolution 5mm probe for precise measurements
- Wide linear range with exceptional sensitivity
- Robust construction for harsh environments
- Advanced signal conditioning for noise immunity
- Compatibility with Bently Nevada monitoring systems
- Easy installation and alignment
Benefits
- Early detection of machinery faults
- Reduced downtime and maintenance costs
- Improved machinery reliability and safety
- Long service life with minimal calibration needs
- Seamless integration into existing systems
- Global technical support and service
Technical Specifications
| Parameter | Specification |
|---|---|
| Probe Diameter | 5mm (0.197 in) |
| Linear Range | 2mm (0.079 in) |
| Sensitivity | 8 V/mm (200 mV/mil) |
| Frequency Response | 0 to 10 kHz (-3 dB) |
| System Linearity | ±1% of full scale |
| Temperature Range | -35°C to +175°C (-31°F to +347°F) |
| Supply Voltage | -24 VDC ±10%, 12 mA max |
| Output Signal | Proportional DC voltage |
| Cable Length | 2 meters (standard) |
| Material | Stainless steel housing, PTFE cable |
| Weight | Approximately 150 grams |
System Components
The Bently Nevada 3701/55 323174-01 system includes the following components:
Probe Assembly
- 5mm diameter probe tip
- Stainless steel housing
- 2-meter PTFE-insulated cable
- Hermetically sealed for moisture resistance
Extension Cable
- 2-meter length (custom lengths available)
- Quad-shielded for EMI/RFI protection
- Weather-resistant connectors
- Impedance matched to probe
Driver
- Signal conditioning electronics
- LED status indicators
- Configurable output options
- Rugged aluminum enclosure
Mounting Hardware
- Probe mounting bracket
- Locknuts and washers
- Installation tools
- Alignment templates
Applications
The Bently Nevada 3701/55 323174-01 system is ideal for monitoring a wide range of rotating machinery in various industries, including:
Turbines
Compressors
Generators
Pumps
Electric Motors
Gearboxes
Ordering Information
Part Number: 323174-01
Model: 3701/55
Manufacturer: Bently Nevada Corporation
Warranty: 2 years standard warranty
Delivery Time: 4-6 weeks from order date
Technical Support
Bently Nevada provides comprehensive technical support for the 3701/55 323174-01 system, including:
- 24/7 global customer service
- On-site installation and commissioning
- Training and certification programs
- Remote monitoring and diagnostics
- Spare parts availability
- System upgrades and enhancements
