ABB ACS800-37-0170-3+B053+G300+H358+L505+Q951+R700 Introduction

1. Product Overview

The ABB ACS800-37-0170-3+B053+G300+H358+L505+Q951+R700 is a cabinet-type drive within the ABB ACS800 series. It is designed for precise control of AC motors in industrial applications, featuring low-harmonic characteristics and meeting relevant industry standards like IEEE 519-1992 for harmonic control.

2. Model and Configuration Details

Base Model (ACS800-37-0170-3)

Belongs to the ACS800-37 series, suitable for power ranges that enable it to handle motor-related tasks such as speed and torque regulation in industrial setups. The “0170” typically relates to the drive's power-handling capacity (around 170 kVA as a common interpretation, though exact specs depend on official docs), and “-3” indicates the voltage class适配 (e.g., 380/400/415 VAC in many cases).

Options Explanation

+B053: Denotes the protection class IP22 (UL type 1). This防护 rating safeguards the drive against access to hazardous parts by ordinary persons and provides protection against water splashing from a general direction, ensuring a basic level of environmental protection for internal components.

+G300: Information about this option is relatively limited from general sources. It may pertain to specific cabinet-related functions or configurations, such as auxiliary equipment installation within the cabinet (exact details need reference to ABB's technical manuals).

+H358: Details are not fully clear without in-depth ABB documentation. It might be associated with cabinet-related structural or connection designs, like inlet/outlet wiring arrangements or internal component mounting适配 (further clarification requires consulting official technical materials).

+L505: Represents a thermistor relay (1 or 2 pieces, and it cannot be selected simultaneously with L506 or L513). It serves to monitor the motor's temperature. When the motor's temperature reaches a pre-set threshold, the relay triggers protective actions to prevent motor damage due to overheating.

+Q951: Stands for Emergency Stop Type 0. In case of a fault, it immediately cuts off the power supply to the drive and connected motor. This function requires the F250 option to be effective, providing a rapid shutdown mechanism for safety-critical situations.

+R700: Specific details are not readily available in general references. It may involve cabinet-related features like enhanced cooling, structural adaptations for specific installation environments, etc. (precise meaning needs to be confirmed with ABB's detailed technical documentation).

3. Application Scenarios

It is widely used in industrial drive systems, such as in manufacturing plants for conveyor belts, pumps, fans, and other motor-driven equipment. The low-harmonic feature makes it suitable for environments where power quality requirements are strict, helping to reduce harmonic interference to the power grid and other connected equipment.

4. General Features

Utilizes Direct Torque Control (DTC) technology for accurate motor torque and speed control, enabling high-performance operation of motors.

Offers reliable protection functions, including over-current, over-voltage, under-voltage, and over-temperature protection, to ensure the safe and stable operation of the drive and connected equipment.

Is compatible with various fieldbus communication protocols (depending on additional communication module options), facilitating integration into industrial automation control systems for centralized monitoring and control.

For the most accurate and detailed technical parameters, installation guidelines, and maintenance information, it is recommended to refer to ABB's official hardware manuals and technical support resources.
