CONVERTEAM P111-6052 High-Voltage DC Link Module
- Product Code: P111-6052
- Availability: In Stock
CONVERTEAM P111-6052
High-Voltage DC Link Module
Product Overview
The CONVERTEAM P111-6052 is a high-performance high-voltage DC link module designed as the energy hub for large variable frequency drive systems. This advanced power module provides stable DC bus voltage and supports four-quadrant energy feedback, making it ideal for high-inertia load applications such as rolling mills and ship propulsion systems.
As a classic power module from the Converteam brand before GE acquisition, the P111-6052 is typically used as a DC intermediate circuit component in Megalink series medium voltage inverters. Its multi-layer laminated busbar design reduces parasitic inductance to less than 15nH, effectively suppressing voltage spikes during IGBT switching.
Key Features
- High voltage rating: 3000VDC
- Large capacitance: 8mF ±5%
- High peak current handling: 1200A
- Low ESR: 3mΩ
- Four-quadrant energy feedback capability
- Multi-layer laminated busbar design
- Blue epoxy resin encapsulation meeting GL classification society fire standards
- Built-in temperature monitoring system
Technical Specifications
Electrical Characteristics
| Rated Voltage | 3000 VDC |
| Capacitance | 8mF ±5% |
| Peak Current | 1200 A |
| ESR (Equivalent Series Resistance) | 3mΩ |
| Parasitic Inductance | <15nH |
Physical Dimensions
| Width | 220 mm |
| Height | 160 mm |
| Depth | 80 mm |
| Weight | Approx. 2.5 kg |
| Mounting | Panel-mount |
Environmental Ratings
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Protection Rating | IP20 |
| Fire Rating | GL Classification Society Standard |
Performance Characteristics
| Voltage Ripple | <2% at 30% voltage fluctuation |
| Charge/Discharge Cycles | 500 cycles per minute (max) |
| Temperature Monitoring | Built-in temperature sensor with fiber optic data transmission |
| Capacitor Technology | Metallized polypropylene film |
Applications
The CONVERTEAM P111-6052 is designed for high-performance power conversion applications requiring stable DC bus voltage and energy feedback capabilities:
- Steel industry: Hot rolling mills and plate mills
- Marine propulsion: Azipod propulsion systems
- Mining: Shield machine cutter drive systems
- Energy storage: Compressed Air Energy Storage (CAES) systems
- Industrial automation: High-power variable frequency drives
- Ship automation: Marine power systems
- Power generation: Grid-connected converters
In steel mill hot rolling applications, the P111-6052 can withstand 500 charge/discharge cycles per minute, making it ideal for high dynamic load applications.
System Integration
Megalink Series Inverters
Designed as a DC intermediate circuit component for Converteam Megalink series medium voltage inverters, providing stable DC bus voltage and supporting four-quadrant operation.
Azipod Propulsion Systems
Works in conjunction with P111-6053 inverter modules in ship electric propulsion systems, maintaining stable operation even with 30% voltage fluctuations.
Control System Interface
Internal temperature sensors transmit data to the control system via optical fibers, enabling real-time monitoring of capacitor bank health status.
Retrofit Compatibility
Compatible with various Converteam products, including gateway module P701000010R for networked control and MVAJ051RA0200B for advanced interface requirements.
Additional Information
Ordering Information
| Part Number | P111-6052 |
| Series | P111 |
| Manufacturer | CONVERTEAM (now part of GE) |
| Country of Origin | France |
Warranty & Support
| Standard Warranty | 1 year |
| Extended Warranty | Available |
| Technical Support | Available through GE Power Conversion |
Certifications
- GL Classification Society Certification
- CE Certified
- RoHS Compliant
- UL Listed
Replacement Information
As CONVERTEAM is now part of GE Power Conversion, this module is compatible with current GE systems and can be replaced with equivalent GE-branded components when required.
