MOOG D136-001-007 Direct Drive Servo Valve
- Product Code: D136-001-007
- Availability: In Stock
MOOG D136-001-007
Direct Drive Servo Valve
Product Overview
The MOOG D136-001-007 is a high-performance direct drive servo valve engineered for precise hydraulic control in industrial and aerospace applications. This advanced valve design eliminates the need for a pilot stage, offering enhanced dynamic response and reduced hysteresis compared to traditional servo valves. It converts electrical control signals into accurate hydraulic flow rates, making it ideal for applications requiring exceptional positioning accuracy, repeatability, and fast response times in demanding operating environments.
Key Features
- • Direct drive technology with no pilot stage for improved response
- • High flow capacity up to 20 gpm (76 l/min) at 1000 psi (69 bar)
- • Low hysteresis (<0.3% of full scale) for precise control
- • Wide operating pressure range up to 5000 psi (345 bar)
- • Compatible with 4-20mA, ±5V, and ±10V electrical input signals
- • Rugged construction with enhanced contamination tolerance
Technical Specifications
| Parameter | Details |
|---|---|
| Flow Capacity | 20 gpm (76 l/min) at 1000 psi (69 bar) pressure drop |
| Operating Pressure | Maximum: 5000 psi (345 bar); Minimum: 100 psi (6.9 bar) |
| Electrical Characteristics | 4-20mA, ±5V DC, or ±10V DC input; 15W max power consumption |
| Dynamic Response | 3 dB frequency: 250 Hz; Rise time: <30 ms |
| Operating Temperature | -54°C to +121°C (-65°F to +250°F) |
| Fluid Requirements | Mineral oil, phosphate ester; ISO 4406 cleanliness code 16/13 or better |
Typical Applications
- Aerospace test equipment and simulation systems
- Industrial press and forming machine control
- Turbocharger test stands and engine dynamometers
- Marine steering and thruster control systems
- Metal processing and rolling mill applications
- Oil and gas exploration equipment control
